List processors 6th Generation Intel Xeon for DELL Poweredge R770 server

May 20, 2025 OLEKSANDR SYZOV

List processors 6th Generation Intel Xeon for DELL Poweredge R770 server

The Dell PowerEdge R770 server supports two Intel Xeon 6th Generation Scalable processors, which are categorized into two main types: Performance-cores (P-cores) and Efficient-cores (E-cores). These processors offer varying core counts, clock speeds, cache sizes, and TDP (Thermal Design Power) to suit different workload requirements.

Here's a list of some of the Intel Xeon 6th Generation Scalable processors compatible with the Dell PowerEdge R770, along with their general specifications. Please note that specific configurations and availability may vary based on Dell's offerings at the time of purchase.

Intel Xeon 6th Gen Efficient-cores (E-cores) for Dell PowerEdge R770:

These processors are optimized for energy efficiency and parallel processing, making them ideal for high-density compute environments.

Intel® Xeon® 6 Efficient 6710E

Cores/Threads: 64C/64T
Base Frequency: 2.4 GHz
Cache: 96 MB
TDP: 205W
Memory: DDR5-5600

Intel® Xeon® 6 Efficient 6740E

Cores/Threads: 96C/96T
Base Frequency: 2.4 GHz
Cache: 96 MB
TDP: 250W
Memory: DDR5-6400

Intel® Xeon® 6 Efficient 6746E

Cores/Threads: 112C/112T
Base Frequency: 2.0 GHz
Cache: 96 MB
TDP: 250W
Memory: DDR5-5600

Intel® Xeon® 6 Efficient 6756E

Cores/Threads: 128C/128T
Base Frequency: 1.8 GHz
Cache: 96 MB
TDP: 225W
Memory: DDR5-6400

Intel® Xeon® 6 Efficient 6766E

Cores/Threads: 144C/144T
Base Frequency: 1.9 GHz
Cache: 108 MB
TDP: 250W
Memory: DDR5-6400

Intel® Xeon® 6 Efficient 6780E

Cores/Threads: 144C/144T
Base Frequency: 2.2 GHz
Cache: 108 MB
TDP: 330W
Memory: DDR5-6400

Intel Xeon 6th Gen Performance-cores (P-cores) for Dell PowerEdge R770:

These processors are designed for demanding, compute-intensive workloads and offer higher per-core performance.

Intel® Xeon® 6 Performance 6505P

Cores/Threads: 12C/24T
Base Frequency: 2.2 GHz
Cache: 48 MB
TDP: 150W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6515P

Cores/Threads: 16C/32T
Base Frequency: 2.4 GHz
Cache: 72 MB
TDP: 150W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6517P

Cores/Threads: 16C/32T
Base Frequency: 3.2 GHz
Cache: 72 MB
TDP: 190W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6527P

Cores/Threads: 24C/48T
Base Frequency: 3.0 GHz
Cache: 144 MB
TDP: 255W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6714P

Cores/Threads: 8C/16T
Base Frequency: 4.0 GHz
Cache: 48 MB
TDP: 165W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6724P

Cores/Threads: 16C/32T
Base Frequency: 3.6 GHz
Cache: 72 MB
TDP: 210W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6730P

Cores/Threads: 32C/64T
Base Frequency: 2.5 GHz
Cache: 288 MB
TDP: 250W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6740P

Cores/Threads: 48C/96T
Base Frequency: 2.1 GHz
Cache: 330 MB
TDP: 270W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6747P

Cores/Threads: 48C/96T
Base Frequency: 2.7 GHz
Cache: 330 MB
TDP: 330W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6760P

Cores/Threads: 64C/128T
Base Frequency: 2.2 GHz
Cache: 330 MB
TDP: 330W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6761P

Cores/Threads: 64C/128T
Base Frequency: 2.5 GHz
Cache: 330 MB
TDP: [Not explicitly listed, but similar to others in this range]
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6767P

Cores/Threads: 64C/128T
Base Frequency: 2.4 GHz
Cache: 330 MB
TDP: 350W
Memory: DDR5-6400

Intel® Xeon® 6 Performance 6787P

Cores/Threads: 86C/172T
Base Frequency: 2.0 GHz
Cache: 336 MB
TDP: 350W
Memory: DDR5-6400

Key Features of Intel Xeon 6th Gen Processors (both P-cores and E-cores) supported by Dell PowerEdge R770:

Architecture: These processors are built on the latest Intel 3 process technology. P-cores use "Granite Rapids" architecture, and E-cores use "Sierra Forest" architecture.
Memory: Support for DDR5 memory, with speeds up to 6400 MT/s for RDIMMs. Some configurations may also support MRDIMM, offering even higher memory bandwidth (up to 8800 MT/s). The R770 supports up to 32 DDR5 DIMM slots, with a maximum capacity of 8 TB.
PCIe Lanes: Support for PCIe 5.0, providing high bandwidth for storage and networking cards.
AI Acceleration: Enhanced AI acceleration features, including Intel® Advanced Matrix Extensions (Intel® AMX), with support for various data types (INT8, BF16, and FP16).
Scalability: The PowerEdge R770 is a two-socket server, allowing for significant processing power and scalability.
Power Efficiency: Both P-cores and E-cores are designed for improved performance per watt compared to previous generations.

For the most accurate and up-to-date information on installed processors, it's always best to check the server's documentation or the system's iDRAC (Integrated Dell Remote Access Controller) interface, which will provide a detailed list of the hardware configured in your specific Dell PowerEdge R770.
