The Dell PowerEdge R760 server supports up to two 4th Generation Intel Xeon Scalable processors (codenamed "Sapphire Rapids"). These processors offer a range of specifications to suit various workloads.

Here's a list of some of the 4th Generation Intel Xeon Scalable processors compatible with the Dell PowerEdge R760, along with their key specifications:

Intel Xeon Platinum Series (4th Gen)

• Intel® Xeon® Platinum 8480+ Processor:
• Cores/Threads: 56 Cores / 112 Threads
• Base Frequency: 2.00 GHz
• Max Turbo Frequency: 3.80 GHz
• Cache: 105 MB
• TDP: 350 W
• Intel® Xeon® Platinum 8468 Processor:
• Cores/Threads: 48 Cores / 96 Threads
• Base Frequency: 2.10 GHz
• Max Turbo Frequency: 3.80 GHz
• Cache: 105 MB
• TDP: 350 W
• Intel® Xeon® Platinum 8462Y+ Processor:
• Cores/Threads: 32 Cores / 64 Threads
• Base Frequency: 2.80 GHz
• Max Turbo Frequency: 4.10 GHz
• Cache: 60 MB
• TDP: 300 W
• Intel® Xeon® Platinum 8460Y+ Processor:
• Cores/Threads: 40 Cores / 80 Threads
• Base Frequency: 2.00 GHz
• Max Turbo Frequency: 3.70 GHz
• Cache: 105 MB
• TDP: 300 W

Intel Xeon Gold Series (4th Gen)

• Intel® Xeon® Gold 6458Q Processor:
• Cores/Threads: 32 Cores / 64 Threads
• Base Frequency: 3.10 GHz
• Cache: 60 MB
• TDP: 350 W
• Intel® Xeon® Gold 6454S Processor:
• Cores/Threads: 32 Cores / 64 Threads
• Base Frequency: 2.20 GHz
• Cache: 60 MB
• TDP: 270 W
• Intel® Xeon® Gold 6448Y Processor:
• Cores/Threads: 32 Cores / 64 Threads
• Base Frequency: 2.10 GHz
• Max Turbo Frequency: 4.10 GHz
• Cache: 60 MB
• TDP: 225 W
• Intel® Xeon® Gold 6444Y Processor:
• Cores/Threads: 16 Cores / 32 Threads
• Base Frequency: 3.60 GHz
• Max Turbo Frequency: 4.00 GHz
• Cache: 45 MB
• TDP: 270 W
• Intel® Xeon® Gold 6442Y Processor:
• Cores/Threads: 24 Cores / 48 Threads
• Base Frequency: 2.60 GHz
• Max Turbo Frequency: 4.00 GHz
• Cache: 60 MB
• TDP: 225 W
• Intel® Xeon® Gold 6438Y+ Processor:
• Cores/Threads: 32 Cores / 64 Threads
• Base Frequency: 2.00 GHz
• Cache: 60 MB
• TDP: 205 W
• Intel® Xeon® Gold 6430 Processor:
• Cores/Threads: 32 Cores / 64 Threads
• Base Frequency: 2.10 GHz
• Max Turbo Frequency: 3.40 GHz
• Cache: 60 MB
• TDP: 270 W
• Intel® Xeon® Gold 6434 Processor:
• Cores/Threads: 8 Cores / 16 Threads
• Base Frequency: 3.70 GHz
• Max Turbo Frequency: 4.10 GHz
• Cache: 22.5 MB
• TDP: 195 W
• Intel® Xeon® Gold 5420+ Processor:
• Cores/Threads: 28 Cores / 56 Threads
• Base Frequency: 2.00 GHz
• Max Turbo Frequency: 4.10 GHz
• Cache: 52.5 MB
• TDP: 205 W
• Intel® Xeon® Gold 5418Y Processor:
• Cores/Threads: 24 Cores / 48 Threads
• Base Frequency: 2.00 GHz
• Max Turbo Frequency: 3.80 GHz
• Cache: 45 MB
• TDP: 185 W
• Intel® Xeon® Gold 5415+ Processor:
• Cores/Threads: 8 Cores / 16 Threads
• Base Frequency: 2.90 GHz
• Cache: 22.5 MB
• TDP: 150 W
• Intel® Xeon® Gold 5412U Processor:
• Cores/Threads: 24 Cores / 48 Threads
• Base Frequency: 2.10 GHz
• Cache: 45 MB
• TDP: 185 W
• Intel® Xeon® Gold 5411N Processor:
• Cores/Threads: 24 Cores / 48 Threads
• Base Frequency: 1.90 GHz
• Cache: 45 MB
• TDP: 165 W

Intel Xeon Silver Series (4th Gen)

• Intel® Xeon® Silver 4416+ Processor:
• Cores/Threads: 20 Cores / 40 Threads
• Base Frequency: 2.00 GHz
• Max Turbo Frequency: 3.90 GHz
• Cache: 37.5 MB
• TDP: 165 W
• Intel® Xeon® Silver 4410Y Processor:
• Cores/Threads: 12 Cores / 24 Threads
• Base Frequency: 2.00 GHz
• Max Turbo Frequency: 3.90 GHz
• Cache: 30 MB
• TDP: 150 W

Intel Xeon Bronze Series (4th Gen)

• Intel® Xeon® Bronze 3408U Processor:
• Cores/Threads: 8 Cores / 16 Threads
• Base Frequency: 1.80 GHz
• Cache: 22.5 MB
• TDP: 125 W

General Specifications for 4th Gen Intel Xeon Scalable Processors (Sapphire Rapids) on Dell PowerEdge R760:

• Number of Processors Supported: Up to two
• Memory Support: DDR5 (up to 4800 MT/s)
• DIMM Slots: 32 DDR5 DIMM slots (16 per CPU)
• Maximum Memory Capacity: Up to 8 TB (with RDIMM)
• PCIe Lanes: Up to 80 PCIe 5.0 lanes per CPU
• UPI Speed: Up to 4 links per CPU, with speeds up to 16 GT/s
• Built-in Accelerators: Designed for AI, data analytics, networking, storage, crypto, and data compression workloads.

Important Notes:

• The exact specifications and availability may vary based on the specific Dell PowerEdge R760 configuration and regional offerings.
• For CPUs with a TDP over 250W, a high-TDP chassis might be required.
• The Dell PowerEdge R760 also supports 5th Generation Intel Xeon Scalable processors.
• Always refer to the official Dell PowerEdge R760 documentation and product configurator for the most accurate and up-to-date information on processor compatibility and options.
